This guide shows you how to test image transformations in PixelFiddler before using them in your application. You’ll learn how to experiment with parameters, preview results, and validate your transformations work as expected.

Prerequisites

Section titled “Prerequisites”

Before you begin, make sure you have:

  • A PixelFiddler account with at least one media source configured
  • An image uploaded to your source — see Serve your first image if you haven’t done this yet

Disable transformation security for testing

Section titled “Disable transformation security for testing”

By default, all transformations are protected by a token. To test transformations directly in your browser, you need to temporarily disable this protection:

  1. Go to Sources and select your source
  2. Navigate to Security settings
  3. Set Transformations security to None

Test in your browser

Section titled “Test in your browser”

The quickest way to test transformations is directly in your browser’s address bar.

Step 1: Get your base image URL

Section titled “Step 1: Get your base image URL”

Start with your image’s base URL:

https://media.pixel-fiddler.com/{sourceAlias}/media/{imagePath}

For example:

https://media.pixel-fiddler.com/my-images/media/photo.jpg

Step 2: Add transformation parameters

Section titled “Step 2: Add transformation parameters”

Append a ? followed by your transformation parameters:

https://media.pixel-fiddler.com/my-images/media/photo.jpg?w=300&h=200

Press Enter and see the transformed image instantly.

Step 3: Experiment with different values

Section titled “Step 3: Experiment with different values”

Modify the URL parameters and refresh to see changes:

https://media.pixel-fiddler.com/my-images/media/photo.jpg?w=300&h=200&bl=5&q=80

Interactive preview

Section titled “Interactive preview”

Try adjusting these parameters to see how transformations affect an image:

0
Preview
<img src="https://media.pixel-fiddler.com/{sourceAlias}/media/{imagePath}?w=300&q=80&bl=0"/>

Common test scenarios

Section titled “Common test scenarios”

Here are some typical transformations to test:

Thumbnail generation

Section titled “Thumbnail generation”
?w=150&h=150&rm=fill&q=80

Creates a 150x150 square thumbnail with the image filling the frame.

Responsive images

Section titled “Responsive images”

Test different sizes for responsive breakpoints:

?w=400    // Mobile
?w=800    // Tablet
?w=1200   // Desktop

Effect combinations

Section titled “Effect combinations”
?w=600&bl=3&ct=60&sa=80

Combines resize with blur, contrast, and saturation adjustments.

Troubleshooting

Section titled “Troubleshooting”

Image not loading

Section titled “Image not loading”
  • Verify your source alias is correct
  • Check that the image path matches exactly (case-sensitive)
  • Ensure your source is properly configured and accessible

Transformation not applied

Section titled “Transformation not applied”
  • Check for typos in parameter names
  • Verify parameter values are within valid ranges
  • Some parameters require specific formats (e.g., colors as hex values)

Unexpected results

Section titled “Unexpected results”
  • The mode parameter affects how resizing behaves — try rm=fit, rm=fill, or rm=pad
  • Some effects are subtle at low values — increase the value to confirm it’s working

Next steps

Section titled “Next steps”

Now that you know how to test transformations:
